Máy photocopy Canon iR 2224N

Machine Type

A3 Monochrome Laser Multifunctional

Core Functions

iR2224N: Print, Copy, Scan, and Send

Control Panel

3.5 inch monochrome touch panel

Memory

1.0 GB RAM

Storage

eMMC: 2 GB

Interface Connection

NETWORK*1
Standard: 100Base-TX/10Base-T, Wireless LAN (IEEE 802.11 b/g/n)

OTHERS Standard:
USB 2.0 (Device) x1

Paper Supply Capacity (A4, 80 gsm)

Standard: 350 sheets (Paper Drawer: 250 sheets, MPT Tray: 100 sheets)
Maximum: 600 sheets (with Cassette Feeding Module-AK1)

Paper Output Capacity (A4, 80 gsm)

Standard: 250 sheets
Maximum: 250 sheets

Supported Media Types

Multi-purpose Tray:
Thin, Plain, Recycled, Thick, Colour, Bond, Label, Pre-punched, Envelope

Paper Cassette:
Plain, Recycled, Colour, Pre-punched

Supported Media Sizes

Multi-purpose tray:
A3, A4, A4R, A5, A5R, B4, B5, B5R,
Envelope (COM10, Monarch, DL, ISO-C5),
Custom size min. 95.0 x 148.0 mm up to 297.0 x 431.0 mm

Paper Cassette:
Standard size: A3, A4, A4R, A5R, B4, B5, B5R

Supported Media Weights

Multi-purpose tray: 60 to 157 gsm
Paper cassettes: 64 to 90 gsm
Duplex: 60 to 90 gsm

Warm-up Time


From Power On: 13 seconds or less*2 *3
From Sleep Mode: 4.3 seconds or less

Dimensions (W x D x H)

iR2224N (with DADF): 627 x 607 x 606 mm　

Installation Space (W x D)

1065 x1285 mm

Weight

iR2224N: Approx. 30.3 kg without toner and Platen cover

Print Speed (BW)

1-sided: Up to 24 ppm (A4), Up to 12 ppm (A3), Up to 11 ppm (A4R)
2-sided: Up to 16.7 ppm (A4), Up to 7.5 ppm (A3), Up to 7.8ppm (A4R)

Print Resolution (dpi)

600 × 600

Page Description Languages

Standard: UFRII
Optional (iR2224N only): PCL6/PCL5

Printing From Mobile and Cloud Application

Apple AirPrint, Canon PRINT Business, Mopria, Canon Print Service

Fonts

PCL fonts: 45 Roman, 10 Bitmap fonts

Operating System

UFRII: Windows® 8.1 / Windows® 10 / Windows® 11 / Windows® Server 2012 / Windows® Server 2012 R2 / Windows® Server 2016 / Windows® Server 2019 / Windows® Server 2022/ macOS (10.12 or later)

PCL: Windows® 8.1 / Windows® 10 / Windows® 11 / Windows® Server 2012 / Windows® Server 2012 R2 / Windows® Server 2016 / Windows® Server 2019 / Windows® Server 2022

Copy Speed

1-sided: Up to 24 ppm (A4), Up to 12 ppm (A3), Up to 11 ppm (A4R)
2-sided: Up to 16.7 ppm (A4), Up to 7.5ppm (A3), Up to 7.8ppm (A4R)

First-Copy-Out Time (BW)

Platen: Approx. 7.4 seconds or less (A4)

Copy Resolution (dpi)

600 x 600

Multiple Copies

Up to 999 copies

Copy Density

Automatic or Manual (9 Levels)

Magnification

25% - 400% (1% Increments)
Preset reduction/enlargement: 25%, 50%, 70%, 100%, 141%, 200%, 400%

Document Feeder Paper Capacity

50 Sheets (80 gsm)

Acceptable Originals and Weights

Platen: Sheet, Book

Document Feeder sheet media weight:
1-sided/2-sided continuous scanning: 52 to 105 gsm (BW/CL)
Only 1-sheet feeding is supported in 37-52 and 105-128 gsm

Supported Media Sizes

Platen: Max. scanning size: 297.0 x 431.8 mm Document Feeder media size: A3, A4, A4R, A5, A5R, B4, B5, B5R
Custom size: 128.0 x 148.0 mm to 297.0 x 431.8 mm　

Scan Speed (ipm: BW/CL, A4)

DADF:
1-sided Scanning: 35/25 (300 dpi, send), 25 (600 dpi, copy)
2-sided Scanning: 12/8 (300 dpi, send), 8 (600 dpi, copy)

Scan Resolution (dpi)

Scan for Copy: up to 600 x 600
Scan for Send: (Push) up to 300 x 600, (Pull) up to 600 x 600

Pull Scan Specifications

ScanGear MF For both TWAIN and WIA

Windows® 8.1/ Windows® 10/ Windows® 11 macOS (10.12 or later)

Destination

iR2224N: Email (SMTP), SMB3.0

Address Book / Speed Dials

iR2224N: LDAP (50) / Local (300) / One-Touch (296)

Send Resolution (dpi)

Push (iR2224N): 300 x 600 (SMB/FTP/Email)
Pull: 50 x 50, 75 x 75, 150 x 150, 200 x 200, 300 x 300, 400 ｘ 400, 600 x 600

Communication Protocol

File*1: SMB3.0 (TCP/IP)
Email*1: SMTP (Send)

File Format

Standard: TIFF, JPEG*4, PDF (Compact)

Authentication and Access Control

Department ID Authentication (Department ID and PIN Login, Function Level Login）

Document Security

Print Security (SecurePrint, Encrypted SecurePrint), Send Data Security (Restricted E-mail/File send functions, Confirming FAX number, Allow/Restrict Fax Driver Transmissions, Allow/Restrict Sending from History)

Network Security

TLS 1.3*5, IPSec, IEEE802.1X authentication, SNMPv3, Firewall Functionality (IP Address Filtering), Enabling/Disabling (Network Applications, Remote UI, USB Interface), G3 FAX separation from LAN, USB Port separation from LAN

Device Security

Standard HDD/SSD Initialize, Job Log Conceal Function, Protecting MFP Software Integrity, Verify System at Startup (NIST SP800-193)

Device Management and Auditing

Administrator Password, Digital Certificate and Key Management*6, Security Policy Setting*6

Operating Environment

Temperature: 10 to 30 ºC
Humidity: 20 to 80% RH (Relative Humidity)

Power Source

Asia: 220-240V 50/60Hz 10A

Power Consumption

Maximum: Approx. 1,500 W
Standby: Approx. 15.5 W
Sleep mode: Approx. 0.9 W

Toner Yield (Estimated Yield @ 6% Coverage)

NPG-59 TONER BK OTH: 10,200 impressions (A4)

Feeder Options

Cassette Feeding Module-AK1

Paper Capacity: 250 sheets x 1 (80 gsm)
Paper Type: Plain, Recycled, Colour, Pre-punched
Paper Size: A3, A4, A4R, A5, B4, B5, B5R
Paper Weight: 64 to 90 gsm
Power Source: Main Unit
Dimensions (W x D x H): 581 x 575 x 92 mm Weight: Approx. 5.8 kg
